Description
| Model Code | B210-II |
|---|---|
| Power Unit | Electric |
| Load Capacity (Q) | 1000 kg |
| Load Centre (c) | 500 mm |
| Lift Heights (h3) from | 2970 mm |
| Travel Speed with/without load | 12/12.5 km/h |
| Lifting Speed with/without load | 0.32/0.52 m/s |
| Turning Radius (Wa) | 1229 mm |
| Battery Voltage/Rated Capacity (5h) | 24V / 400-500 Ah |
| Model Code | B213-II |
|---|---|
| Power Unit | Electric |
| Load Capacity (Q) | 1250 kg |
| Load Centre (c) | 500 mm |
| Lift Heights (h3) from | 2970 mm |
| Travel Speed with/without load | 12/12.5 km/h |
| Lifting Speed with/without load | 0.32/0.52 m/s |
| Turning Radius (Wa) | 1391 mm |
| Battery Voltage/Rated Capacity (5h) | 24V / 735-875 Ah |
| Model Code | B215-II |
|---|---|
| Power Unit | Electric |
| Load Capacity (Q) | 1500 kg |
| Load Centre (c) | 500 mm |
| Lift Heights (h3) from | 2970 mm |
| Travel Speed with/without load | 12/12.5 km/h |
| Lifting Speed with/without load | 0.31/0.52 m/s |
| Turning Radius (Wa) | 1420 mm |
| Battery Voltage/Rated Capacity (5h) | 24V / 735-875 Ah |
