Description

Model Code R316
Rated Capacity 1600 kg
Operator Type Ride-on
Mast Type Triplex Freelift
Lift Heights (h23) from 4900 mm
Maximum Lift Height (h23) 13000 mm
Travel Speed with/without load 10.0/11.0 km/h
Lift Speed with/without load 0.36/0.68 m/s (0,50/0,68 m/s option)
Lowering Speed with/without load 0.55/0.59 m/s
Chassis Width (b1) 1270 mm
Battery Compartments Standard / Sideways change
Battery Voltage/Nominal Capacity K5 48V / 465 – 930 Ah
Drive/Lift Motor Power 7.5/11.0 kW (7,5 – 15 kW option)
