Description
| Model Code | R116 |
|---|---|
| Rated Capacity | 1600 kg |
| Operator Type | Ride-on |
| Mast Type* | DT/TF |
| Lift Heights (h23) from | 3000 mm |
| Maximum Lift Height (h23) | 8500 mm |
| Travel Speed with/without load | 10 km/h |
| Lift Speed with/without load | 0.28/0.43 m/s |
| Lowering Speed with/without load | 0.52/0.52 m/s |
| Chassis Width (b1) | 1270 mm |
| Battery Compartments | Standard / Sideways change |
| Battery Voltage/Nominal Capacity K5 | 48V / 620 Ah |
| Drive/Lift Motor Power | 5/10 kW |
* Mast Type: Duplex Tele (DT), Triplex Freelift (TF)
